Specifications
| Details |
| Product code |
CCR2116-12G-4S+ |
| Architecture |
ARM 64bit |
| CPU |
AL73400 |
| CPU core count |
16 |
| CPU nominal frequency |
2000 MHz |
| Switch chip model |
98DX3255 |
| Dimensions |
443 x 199 x 44 mm |
| RouterOS license |
6 |
| Operating System |
RouterOS v7 |
| Size of RAM |
16 GB |
| Storage size |
128 MB |
| Storage type |
NAND |
| MTBF |
Approximately 200'000 hours at 25C |
| Tested ambient temperature |
-20°C to 60°C |
| IPsec hardware acceleration |
Yes |
Powering
| Details |
| Number of AC inputs |
2 |
| AC input range |
100-240 |
| Max power consumption |
83 W |
| Max power consumption without attachments |
60 W |
| Cooling type |
4 fans |
Ethernet
| Details |
| 10/100/1000 Ethernet ports |
13 |
Fiber
Peripherals
| Details |
| Serial console port |
RJ45 |
| Number of M.2 slots |
1 |
Other
| Details |
| CPU temperature monitor |
Yes |
| PCB temperature monitor |
Yes |
| Mode button |
Yes |
Certification & Approvals
| Details |
| Certification |
CE, EAC, ROHS |
Included parts
-
IEC cord
-
IEC cord
-
Rackmount bracket white
-
K-57 kit
The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..
