Specifications
| Details |
| Product code |
CRS318-16P-2S+OUT |
| Architecture |
ARM 32bit |
| CPU |
98DX226S |
| CPU core count |
1 |
| CPU nominal frequency |
800 MHz |
| Switch chip model |
98DX226S |
| Dimensions |
303 x 212 x 78 mm |
| RouterOS license |
5 |
| Operating System |
RouterOS / SwitchOS |
| Size of RAM |
256 MB |
| Storage size |
16 MB |
| Storage type |
FLASH |
| MTBF |
Approximately 200'000 hours at 25C |
| Tested ambient temperature |
-40°C to 70°C |
Powering
| Details |
| Number of DC inputs |
2 (DC jack) |
| DC jack input Voltage |
18-30 V / 48-57 V |
| Max power consumption |
316 W |
| Max power consumption without attachments |
16 W |
| Cooling type |
Passive |
PoE-out
| Details |
| PoE-out ports |
Ether1-Ether16 |
| PoE out |
802.3af/at |
| Max out per port output (input 18-30 V) |
1.1 A |
| Max out per port output (input 30-57 V) |
0.6 A |
| Max total out (A) |
2.8A (18V-30V) & 1.4A (48V-57V) x2 A |
Ethernet
| Details |
| 10/100/1000 Ethernet ports |
16 |
| Number of 1G Ethernet ports with PoE-out |
16 |
Fiber
Other
| Details |
| CPU temperature monitor |
Yes |
| Voltage Monitor |
Yes |
Certification & Approvals
| Details |
| Certification |
CE, EAC, ROHS |
| IP |
IP54 |
Included parts
-
Hose clamp 2
-
K-66 fastening set
-
DC to Terminal block adapter x2
The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..
