Specifications
| Details |
| Product code |
CRS326-24S+2Q+RM |
| Architecture |
MIPSBE |
| CPU |
QCA9531 |
| CPU core count |
1 |
| CPU nominal frequency |
650 MHz |
| Switch chip model |
98DX8332 |
| Dimensions |
443 x 200 x 44 mm |
| RouterOS license |
5 |
| Operating System |
RouterOS v7 / SwitchOS |
| Size of RAM |
64 MB |
| Storage size |
16 MB |
| Storage type |
FLASH |
| MTBF |
Approximately 200'000 hours at 25C |
| Tested ambient temperature |
-20°C to 60°C |
Powering
| Details |
| Number of AC inputs |
2 |
| AC input range |
100-240 |
| Max power consumption |
69 W |
| Max power consumption without attachments |
42 W |
| Cooling type |
3 fans |
Ethernet
| Details |
| 10/100 Ethernet ports |
1 |
Fiber
| Details |
| SFP+ ports |
24 |
| Number of 40G QSFP+ ports |
2 |
Peripherals
| Details |
| Serial console port |
RJ45 |
| Number of USB ports |
1 |
| USB Power Reset |
Yes |
| USB slot type |
USB type A |
| Max USB current (A) |
1 |
Certification & Approvals
| Details |
| Certification |
CE, EAC, ROHS |
| IP |
IP20 |
Included parts
-
Screw and feet kit (K10)
-
2x IEC cords
-
Rack ears
The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..
